Condential 9
HD20/HD200X/HD2200/HD20LV/HD21/HD23
Item P/N Description Parts Supply
70.8EG35GR01
ASSY BOTTOM COVER MODULE FOR
HD20(SERVICE)
V
70.8HW02GR01 ASSY BOTTOM COVER MODULE FOR HD20LV
WHITE(SERVICE)
V
1 51.8EG01G001 HD20 BOTTOM COVER MN3600H
V
2 52.8BA02G001 ADJUST FOOT P1266
3 86.00122G015 NUT HEX M2.0*0.4P L15 Ni
4 61.8EG01G001 8EG BOTTOM SHIELDING T=0.6MM
5 61.8BB09G001 SECURITY BAR EX525ST
6 51.8BB15G001 SECURITY BAR CAP PC MN3600H BLACK EX525ST
7 85.WA123G050 SCREW PAN TAP M3*5 Ni
8 41.89K04G001 EMI GASKET W8*H6*L150
