Operating 81-
value of the hysteresis before the algorithm takes it as a new minimum value.
U °C
Setup of the Temperature unit [°C or °F].
M 01
Setup of the Multidrop address. In a RS485 network each sensor will need a specific
address. This menu item will only be shown if a RS485 interface board is plugged in. For
using the RS422 mode, press once the down button on M01.
BAUD 115.2K
Setup of the Baud rate for digital data transfer.
S OFF
Activating (ON) and Deactivating (OFF) of an optional Sighting Laser [►3.3 Further
Accessories]. By pressing Up or Down a voltage of 3 VDC will be switched to the PINK
connection pin on the mainboard.
Peak picking function
For a detection of fast hotspots (detection time 90 µs) the averaging time must be set to 0.0 s.
You can display the process temperature TProc (with post processing) and also the current
average temperature TAvg (without any post processing) in the diagram. In this way the result
and functionality of the selected post processing features can easily be traced and controlled.
Signal Graphs
