-50 -
3.3 Further Accessories
Right Angle Mirror [ACCTRAM]
for optics with a D:S ≥ 10:1;
enables measurements with 90° angle to sensor axis.
Laser-Sighting tool [D08ACCTLST]
battery powered (2x Alcaline AA), for alignment of CT
sensing heads. The laser head has the same mechanical
dimensions as the CT sensing head.
WARNING: Do not point the laser directly at the eyes of
persons or animals! Do not stare into the laser beam.
Avoid indirect exposure via reflective surfaces!
The mirror has a reflexion of 96% in combination with a LT22 and LT15 head and 88%
with a LT15F head.
If the mirror is used this value has to be multiplied by the emissivity value of the
measurement object.
Example: LT22 and object with emissivity = 0,85
0,85 x 0,96 = 0,816
Thus the emissivity in the CT has to be set to the resulting value of 0,816.
