Oracle EXADATA X5-2 Installation Guide

Back Panel Status Indicators, Connectors, Drives, and PCIe Slots
Call Out Description
5 SP OK LED: green
6 NVM-Express SSDs 0 through 5
7 NVM-Express SSDs 6 through 11
8 USB 2.0 connectors (2)
9 Service Required LEDs (3): Top: Fan Module (amber); Rear: Power Supply (amber);
Overtemp Icon: System Over Temperature Warning (amber)
Related Information
■
“Back Panel Status Indicators, Connectors, Drives, and PCIe Slots” on page 12
■
“Storage Server Components” on page 10
Back Panel Status Indicators, Connectors, Drives, and PCIe
Slots
This section shows the Oracle Exadata Storage Server X5-2 Extreme Flash back panel and
describes its controls, connectors, and status indicators (LEDs).
Call Out Description
1 Power supply unit 0 (PS0)
2 Power supply unit 1 (PS1)
3 PCIe slot 1 (Oracle PCIe NVMe switch card)
12 Oracle Exadata Storage Server X5-2 Extreme Flash Installation Guide • July 2018
