Install Mounting Brackets
Caution - Shipping brackets are not for use for bracing or anchoring the rack during seismic
events.
Related Information
■
“Safety Precautions When Rackmounting the Storage Server” on page 26
■
“System Specifications” on page 15
■
Your rack cabinet documentation
■
Oracle Exadata Storage Server X5-2 Extreme Flash Safety and Compliance Guide
Install Mounting Brackets
To install the mounting brackets onto the sides of the storage server:
1.
Position a mounting bracket against the chassis so that the slide-rail lock is at
the storage server front, and the five keyhole openings on the mounting bracket
are aligned with the five locating pins on the side of the chassis.
30 Oracle Exadata Storage Server X5-2 Extreme Flash Installation Guide • July 2018
