Power Specifications
Set conditions to the optimal temperature and humidity ranges to minimize the chance of
downtime due to component failure. Operating the storage server for extended periods at or
near the operating range limits, or installing it in an environment where it remains at or near
nonoperating range limits could significantly increase hardware component failure.
Power Specifications
The storage server uses AC power. The values in the following table are the power supply
specifications.
Note - The power dissipation numbers listed in the following table are the maximum rated
power numbers for the power supply used in the system. The numbers are not a rating of the
actual power consumption of the system.
TABLE 4
Power Supply Specifications
Parameter AC Requirement
Voltage (nominal) 100 to 127/200 to 240 VAC
Input current (maximum)
12 A–8.5 A @ 100–127 VAC
5.7 A @ 200–240 VAC
Frequency 50/60 Hz (47 to 63 Hz range)
Shipping Carton Space Requirements
The following table lists the dimensions and weights for the shipping cartons that contain the
Oracle Exadata Storage Server X5-2 Extreme Flash.
TABLE 5
Shipping Carton Specifications
Requirement Specification
Shipping carton height 30.5 cm (12 inches)
Shipping carton width 59.9 cm (23.6 inches)
Shipping carton length 98.4 cm (38.7 inches)
Shipping carton weight 5.8 kg (12.8 lbs)
When the storage server is unloaded at your site, leave the storage server in its shipping carton
until it arrives in its installation location. Use a separate area in which to remove the packaging
System Specifications 17
