Remove the Cable Management Arm
Remove the Cable Management Arm
Follow this procedure to remove the cable management arm (CMA).
Before you begin this procedure, refer to the illustration in Step 1 and identify CMA connectors
A, B, C, and D. You should disconnect the CMA connectors in the reverse order in which you
installed them, that is, disconnect connector D first, then C, then B, and finally A.
Throughout this procedure, once you disconnect any of the CMA's four connectors, do not
allow the CMA to hang under its own weight.
Note - References to “left” or “right” in this procedure assume that you are facing the back of
the equipment rack.
1.
To prevent the rack from tipping forward when the storage server is extended,
extend all rack anti-tilt devices.
Caution - To reduce the risk of personal injury, stabilize the rack cabinet and extend all anti-tilt
devices before extending the storage server from the rack.
For instructions for stabilizing the rack, see “Stabilize the Rack for Installation” on page 29.
2.
Disconnect all cables from the rear of the storage server.
3.
To make it easier to remove the CMA, extend the storage server approximately
13 cm (5 inches) out of the front of the rack.
4.
To remove the cables from the CMA:
a.
If applicable, remove any additional Velcro straps that were installed to
bundle the cables.
b.
Unwrap the six Velcro straps that are securing the cables.
c.
Open the three cable covers to the fully opened position.
d.
Remove the cables from the CMA and set them aside.
5.
To disconnect connector D:
Installing the Storage Server Into a Rack 55
