Cabling the Storage Server
This section contains procedures for connecting data and system management cables and power
cords to the storage server.
Description Links
Review connector port locations. “Rear Cable Connections and Ports” on page 61
Learn about storage server Ethernet ports. “Ethernet Ports” on page 63
Connect power cords to the storage server. “Connect the Power Cords” on page 64
Related Information
■
“Rack Installation Procedure Overview” on page 19
Rear Cable Connections and Ports
The following figure shows the locations of cable connectors and ports on the back of the
Oracle Exadata Storage Server X5-2 Extreme Flash and the cables and devices that you would
typically connect to them.
Cabling the Storage Server 61
