Rackmount Kit Contents
Related Information
■
“Installing the Storage Server Into a Rack” on page 25
Rackmount Kit Contents
The rackmount kit contains two slide-rails, two mounting brackets, and optional securing
screws.
Note - Refer to the rackmount kit installation card for simplified instructions about installing
your storage server into a four-post rack, using the slide-rail and cable management arm
options.
Call Out Description
1 Slide-rails
2 Mounting brackets
3 Four M4 x 5 fine-pitch mounting bracket securing screws (not used)
4 Installation card
Related Information
■
“Rack Requirements” on page 20
28 Oracle Exadata Storage Server X5-2 Extreme Flash Installation Guide • July 2018
