Connect the Power Cords
For the location of the status indicator LEDs, see “Front Panel Status Indicators, Connectors,
and Drives” on page 11 and “Back Panel Status Indicators, Connectors, Drives, and PCIe
Slots” on page 12.
Caution - Do not operate the storage server unless all fans, component heatsinks, air baffles,
and the top cover are installed. Damage to storage server components can occur if the storage
server is operated without adequate cooling mechanisms.
Note - Do not apply main power to the rest of the storage server until you are ready to configure
a preinstalled operating system or perform a fresh installation of an operating system. At this
point, power is supplied only to the SP and the power supply fans.
Related Information
■
“Rear Cable Connections and Ports” on page 61
■
“Ethernet Ports” on page 63
Cabling the Storage Server 65
