Table 2-3 (Cont.) Technical Specifications for the MICROS Workstation 820
Feature Description
Dimensions • Workstation only: 329.11mm x 215.79mm x 17mm (12.95 x 8.49 x
0.67 inches)
• Workstation with Vertical Stand: 329.11mm x 289mm x 182mm
(12.95 x 11.38 x 7.17 inches)
• Workstation with Low Prole Stand: 329.11mm x 100mm x 296mm
(12.95 x 3.94 x 11.65 inches)
• Workstation with Low Prole Stand and Customer Facing Display:
329.11mm x 100mm x 314mm (12.95 x 3.94 x 12.36 inches)
All measurements are approximate.
Operating
Temperature and
Humidity
0 °C (32 °F) to 50 °C (122 °F); 90% Max relative humidity (non-
condensing)
Enclosure • IP Rating: Workstation 8 System Unit: IP54. When used with the
optional Peripheral Expansion Module: IP34.
• All-aluminum casework provides passive system cooling (no fans)
Certications FCC Class A, UL, CE, TUV, RoHS, China RoHS
*The Workstation 820 enclosure is non-serviceable. Internal components cannot be
upgraded.
Chapter 2
Technical Specifications
2-6
