Ordering
Library Overview 1-19
■ Active capacity
■ Partitioning
■ Dual TCP/IP
■ Multi TCP/IP
Physical Configuration
Order a base library, select the desired number of SEMs, and corresponding rail kit.
Base Library
The base library includes a CIM, SEM, RIM, DEM, operator panel, four robots, CAPs,
service safety door, and web cameras. It is the smallest configuration you can order.
Storage Expansion Modules (SEMs)
The library can contain up to 5 SEMs to increase the capacity of the library.
Rail Kits
Order one rail kit that correspond to the total number of SEMs.
Hardware Options
■ Accessory Racks
■ Cartridge Access Ports
■ Internal Ethernet Switch
■ Pass-thru Ports
■ Redundant Electronics
■ Robots
■ Service Safety Door
■ Touchscreen Op Panel
Base Library Part Number Description ATO
Base Module with 1,360 slots (2,000 active slots) 7113666
Base Module with 1,360 slots (2,000 active slots) for non-EU countries 7114548
SEM Part Number Description ATO PTO
SEM with 1,728 slots (no active slots) 7100898 SL8500-EXP-FRZ-N
Rail Kit Part Number Description ATO PTO
Rail kit for one SEM 7100886 XSL8500-1EF-RAIL-N
Rail kit for two SEMs 7100888 XSL8500-2EF-RAIL-N
Rail kit for three SEMs 7100889 XSL8500-3EF-RAIL-N
Rail kit for four SEMs 7100891 XSL8500-4EF-RAIL-N
Rail kit for five SEMs 7100892 XSL8500-5EF-RAIL-N
