Installation Site Requirements
2-4 StorageTek SL8500 Library Guide
Package Component Weights and Dimensions
The package weights and dimensions for additional components are listed below:
Installation Site Requirements
■ Physical Space
■ Floor Requirements
■ Ceiling Requirements
7 Basic library rails (no SEMs) 33 cm (13 in.) 112 cm (44 in.) 125 cm (49 in.) 100 kg (220 lb)
7A Rail Kit for one SEM 33 cm (13 in.) 112 cm (44 in.) 218 cm (86 in.) 182 kg (400 lb)
7B Rail Kit for two SEMs 33 cm (13 in.) 112 cm (44 in.) 315 cm(124 in.) 272 kg (600 lb)
7C Rail Kit for three SEMs 51 cm (20 in.) 112 cm (44 in.) 315 cm(124 in.) 372 kg (820 lb)
7D Rail Kit for four SEMs 51 cm (20 in.) 112 cm (44 in.) 315 cm(124 in.) 395 kg(871 lbs)
7E Rail Kit for five SEMs 46 cm (18 in.) 107 cm (42 in.) 310 cm(122 in.) 416 kg (917 lb)
8 Base Module Arrays 122 cm (48 in.) 115 cm (45 in.) 150 cm (59 in.) 161 kg (355 lb)
8A SEM Arrays (one per SEM) 122 cm (48 in.) 115 cm (45 in.) 153 cm (60 in.) 171 kg (377 lb)
9 Covers and Rear Doors 112 cm (44 in.) 114 cm (45 in.) 254 cm(100 in.) 346 kg (762 lb)
9A Bulk CAP, safety door, op
panel
112 cm (44 in.) 114 cm (45 in.) 254 cm(100 in.) 296 kg (652 lb)
10 4 Robots (additional pallet
with redundant robotics)
72 cm (28 in.) 97 cm (38 in.) 140 cm (55 in.) 65 kg (143 lb)
PF PLT Performance Kit 61 cm (24 in.) 107 cm (42 in.) 107 cm (42 in.) 38 kg (84 lb)
Table 2–6 Component Package Weights and Dimensions
Description Height Width Length Weight
Rotational CAP 36 cm (14 in.) 38 cm (15 in.) 229 cm (90 in.) 22 kg (48 lb)
Façade- Upper and Lower (pallet 9) 13 cm (5 in.) 49 cm (19 in.) 242 cm (95 in.) 19 kg (40 lb)
Copper Kit for Rails 76 in. (pallet 7A) 8 cm (3 in.) 44 cm (17 in.) 196 cm (77 in.) 9 kg (20 lb)
Copper Kit for Rails 114 in. (pallet 7B ) 8 cm (3 in.) 92 cm (36 in.) 178 cm (70 in.) 12 kg (25 lb)
Copper Kit for Rails +114in. (pallet 7C) 8 cm (3 in.) 92 cm (36 in.) 178 cm (70 in.) 14 kg (30 lb)
Drive Bay 94 cm (36 in.) 59 cm (23 in.) 83 cm (32 in.) 37 kg (80 lb)
HBS 16 cm (6 in.) 26 cm (10 in.) 61 cm (24 in.) 5 kg (10 lb)
Op Panel/Display 31 cm (12 in.) 41 cm (16 in.) 46 cm (18 in.) 11 kg (23 lb)
PDU 28 cm (11 in.) 74 cm (29 in.) 74 cm (29 in.) 9 kg (19 lb)
PDU N+1 21 cm (8 in.) 61 cm (24 in.) 69 cm (27 in.) 9 kg (19 lb)
Power Supplies 23 cm (9 in.) 26 cm (10 in.) 46 cm (18 in.) 5 kg (10 lb)
Drive Tray - Common SL8500 31 cm (12 in.) 33 cm (13 in.) 102 cm (40 in.) 14 kg (30 lb)
Drive - Common 107 cm (42 in.) 107 cm (42 in.) 138 cm (54 in.) 173 kg (380 lb)
LTO Drive on SL8500 Tray 31 cm (12 in.) 33 cm (13 in.) 102 cm (40 in.) 12 kg (26 lb)
9940 Drive on SL8500 Tray 31 cm (12 in.) 33 cm (13 in.) 125 cm (49 in.) 18 kg (38 lb)
9940 Drive 107 cm (42 in.) 72 cm (28 in.) 127 cm (50 in.) 118 kg (260 lb)
Rack Module (19" Rack) 64 cm (25 in.) 51 cm (20 in.) 92 cm (36 in.) 19 kg (40 lb)
Safety Door 33 cm (13 in.) 66 cm (26 in.) 229 cm (90 in.) 20 kg (42 lb)
Table 2–5 (Cont.) Shipping Pallets –Weights and Dimensions
Pallet Description Height Width Length Weight
