ZS3-2 Controller Hardware Overview
FIGURE 31
ZS3-2 Controller Motherboard, Memory
, and PCIe Components
Figure Legend
1
Drive cage (FRU)
5
Airduct
9
Battery
2
Drive backplane (FRU)
6
PCIe Risers (FRU)
10
PDB duct
3
Motherboard (FRU)
7
PCIe cards
11
Power distribution board (FRU)
164
Oracle ZFS Storage Appliance Customer Service Manual • July 2016
163
165
