7320 Controller Hardware Overview

TABLE 36

7320 Clustered Controllers Configurations

Slot Type Part Number Vendor Part Description Note

0 PCIe 375-3617-01 Intel Niantic DP Optical

10GE NIC

Optional

Recommended

Front-end

0 PCIe 375-3696-01 Mellanox InfiniBand HCA Optional

Recommended

Front-end

0 PCIe 375-3606-03 MHJH29-XTC InfiniBand HCA Optional

Recommended

Front-end

0 PCIe 375-3481-01 Intel

EXPI9404PT

QP Copper NIC Optional

Recommended

Front-end

0 PCIe 371-4325-01 QLogic 8Gb DP FC

HBA

Optional

FC Target

or Initiator

(Backup)

1 PCIe 542-0298-01 Sun Fishworks

Cluster Card 2

Cluster Base

Configuration

2 PCIe 375-3609-03 Sun Thebe External SAS

HBA

Cluster Base

Configuration

7320 Front and Back Panel Components

7320 Front Panel Components - The following figure and legend identify the front panel

LEDs.

232 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
