7120 Controller Hardware Overview
7120 Base Configuration
The following table shows the configuration options for a 7120 controller. All PCIe cards are
low-profile, and must be fitted with low-profile mounting brackets.
This table describes base configurations for the 7120 with Aura Logzilla.
TABLE 43
7120 Standalone Controller Base Configurations for Aura Logzilla
Mktg Part Number Description Mfg Part Number
TA7120-12TB S7120, 1xCPU, 24GB, 12TB 597-0754-01
TA7120-24TB S7120, 1xCPU, 24GB, 24TB 597-0755-01
The following table describes base configurations for the 7120 with Logzilla 3.5" SSD.
TABLE 44
7120 Standalone Controller Base Configurations for Logzilla 3.5" SSD
Mktg Part Number Description Mfg Part Number
7101282 S7120, 1xCPU, 24GB, 3.3TB 7014523
7101284 S7120, 1xCPU, 24GB, 6.6TB 7014525
7120 Chassis Overview
The Sun ZFS Storage 7120 is an enterprise-class two-socket rackmount x64 system powered
by the Intel Xeon processor. It packs high performance and room for growth with four PCIe
slots and 18 DIMM slots into a compact 2U footprint. Refer to the product site at https://www.
oracle.com/storage/nas/index.html for the most recent component specification.
Refer to the white paper Implementing Fibre Channel SAN Boot with Oracle's Sun ZFS Storage
Appliance at http://www.oracle.com/technetwork/articles/servers-storage-admin/
fbsanboot-365291.html for details on FC SAN boot solutions using the Sun ZFS Storage
7120.
The 7120 is a standalone controller that consists of an internal SAS-2 HBA providing disk shelf
expansion, write flash acceleration, and 11 x 300GB 15K, 600GB 15K, 1TB 7.2K, 2TB 7.2K,
or 3TB 7.2K hard drive storage. The SAS-2 storage fabric supports a greater number of targets,
greater bandwidth, higher reliability, and bigger scale.
242 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
