ZS3-2 Controller Hardware Overview
The ZS3-2 controller replaceable memory components and part numbers are listed below.
TABLE 26
ZS3-2 Controller Replaceable Memory Components
Component Description FRU/CRU Part Number
CPU Intel E5-2658, 2.1G, 8-core FRU 7019701
Memory DIMM, 16GB,DDR3,1600,2Rx4,1.35V CRU 7041603
Memory DIMM, 32GB,DDR3,1066,4Rx4,1.35V CRU 7055964
ZS3-2 Storage, Power, and Fan Components - The ZS3-2 controller's internal storage,
power, and cooling components are described in the following figure and legend. A component
identified as a field replaceable unit (FRU) must be replaced by trained Oracle service
technicians.
166 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
