ZS3-2 Controller Hardware Overview

Figure Legend

4 LED board (FRU) 8 PDB signal cable (FRU) 12 Power supplies

ZS3-2 Internal Cables - The ZS3-2 controller contains the following field-replaceable unit

(FRU) internal cables. FRUs are not customer-serviceable, and must be replaced by trained

Oracle service technicians.

FIGURE 34

ZS3-2 Controller Internal Cables

Figure Legend

1 PDB signal cable 3 Drive signal cable 5 Drive power cable

2 USB board cable 4 LED board cable

168 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
