Oracle ZFS ZS3 Series User Manual

Disk Shelf Hardware Overview
Shelf Device Types Data Slots Cache/Log Slots Notes/
Examples
(filler), Slot 23
(filler)
20 Data and 1-4
Cache devices
0 - 19 20 - 23 Software version
OS8.6.0 (or later)
is required for read
cache devices.
Up to four read
cache devices
installed in
consecutive slots.
Example slot
configuration:
Slot 20 (Cache), Slot
21 (Cache), Slot
22 (filler), Slot 23
(filler)
20 Data and 1-4 Log
or Cache devices
0 - 19 20 - 23 Twenty HDD data
devices and up to
four log and cache
devices installed in
consecutive slots.
Software version
OS8.6.0 (or later)
is required for read
cache devices.
Example slot
configurations:
Slot 20 (Log), Slot
21 (Cache), Slot
22 (Log), Slot 23
(Cache)
Sun Disk Shelf
(DS2)
Data 0 - 23 none Fully populated
HDD data devices.
20 Data and 1-4 Log
devices
0-23 20-23 20 HDD data devices
and up to four SSD
log devices installed
in consecutive slots.
Note - Read cache
devices cannot be
