SAW CHAIN
SAW CHAIN
OREGON
®
MICRO-LITE™
Toe
TOOLS FOR FILING
PART N°. DESCRIPTION
70511 4.5mm Round File
29192 4.5mm Assembled File Guide
27530 .025" (0.65mm) Depth-gauge Tool
12211 Depth-gauge File (flat)
90403 Sharpening kit
FILING
➍ TOP-PLATE FILING
ANGLE:
Kickback
Reducing
Features
End View Use
Chain on this page is intended for use with saws up to 2.4 cu. in.
displacement (40cc), bars for electric saws up to 16 in. (41 cm) and
gasoline saws up to 14 in. (35cm).
➊ DEPTH-GAUGE
SETTING:
➋ TOP-PLATE CUTTING ANGLE:
➌ SIDE-PLATE
ANGLE:
➎ FILE-GUIDE
ANGLE
CHAIN TYPE GAUGE
90SG .043" (1.1mm)
MICRO-LITE ™ 90
