IG-267-EN versión 01; 07/04/2017
55
General Instructions
ekor.rpa
Technical characteristics of the equipment
7.5. Climatic tests
Damp heat
IEC 60068-2-78 (2001) 40 °C; 93 % humidity; 96 h
Dry heat
IEC 60068-2-2 (2007) 70 °C; 16 h
Cold
IEC 60068-2-1 (2001) 25 °C; 16 h
Temperature variation
IEC 60068-2-14 (2009) - 25 °C/70 °C; 3 + 3 h; 5 cycles
Table 7.5. Climatic tests
7.6. Mechanical tests
Vibration
IEC 60068-2-64 (2008) Fh
7.82 m/s2; 3 x 30 min; X, Y, Z axes:
- 5 – 20 Hz: 1 m2/s3
- 20 – 200 Hz: - 3 dB/octave
ETSI EN 300 019-2-2 (2012-01) CLASS 2.3 (random)
IP Protection grade
IEC 60529 (1989) + A1 (1999) IP2XB
Table 7.6. Mechanical tests
7.7. Power tests
No-load cable making and breaking
IEC 60265-1 (1999) 24 - 36 kV; 85 A
Mainly active load making and breaking
IEC 60265-1 (1999) 24 - 36 kV; 200 A ; cos(ϕ)= 0.7
24 - 36 kV; 630 A ; cos(ϕ)= 0.7
Earth fault making and breaking
IEC 60265-1 (1999) 24 - 36 kV; 200 A; IN= 50 A; cos(ϕ)= 0,7
24 - 36 kV; 200 A; IN= 5 A; cos(ϕ)= 0,7
Short-circuit making and breaking
IEC 60265-1 (1999) 3 kV; 1 kA
10 kV; 3 kA
3 kV; 10 kA
3 kV; 16 kA
Table 7.7. Power tests
7.8. CE Conformity
This product complies with the European Union directive
2014/30/EU on electromagnetic compatibility, and with
the IEC 60255 international regulations. The unit has been
designed and manufactured for use in industrial areas,
in accordance with EMC standards. This conformity is a
result of the test carried out in accordance with article 7 of
the Directive.
