Ormazabal ekor.rpa Series User Manual

IG-267-EN versión 01; 07/04/2017
82
Log record General Instructions
ekor.rpa
10.1.3. List of available signals
Unit:
type/group
Subgroup Type
Records
Fault report unit
• Pre-fault event
• Reason for end fault:
• UPs OFF, Fault cleared
• Loss of power (V
dc
KO. Autosaved PowerDown)
• Timeout reached. (Fault not cleared)
• Fault saved, External trip
• End fault case unknown
Timed overcurrent unit
(UNIT 51)
Phase_1,2,3,N and NS
(P1)
(P2)
(P3)
(N)
(NS)
• Curve started up (PICK UP ON/OFF)
• Curve met (TEMPORIZED ON/OFF)
• Unit blocked (UNIT BLOCK ON/OFF)
• Timing Blocked (TIMING BLOCK ON/OFF)
• Tripping Blocked (TRIPPING BLOCK ON/OFF)
• Trip (TRIP ON)
• No trip by counter direction (NO TRIP DIR ON)
• No trip by blocked unit (NO TRIP BLOCK ON)
Timed overcurrent unit
(UNIT 51(2))
Phase_1,2,3,N and NS
(P1)
(P2)
(P3)
(N)
(NS)
• Curve started up (PICK UP ON/OFF)
• Curve met (TEMPORIZED ON/OFF)
• Unit blocked (UNIT BLOCK ON/OFF)
• Timing Blocked (TIMING BLOCK ON/OFF)
• Tripping Blocked (TRIPPING BLOCK ON/OFF)
• Trip (TRIP ON)
• No trip by counter direction (NO TRIP DIR ON)
• No trip by blocked unit (NO TRIP BLOCK ON)
Instantaneous overcurrent
unit
(UNIT 50)
Phase_1,2,3,N and NS
(P1)
(P2)
(P3)
(N)
(NS)
• Curve started up (PICK UP ON/OFF)
• Curve met (TEMPORIZED ON/OFF)
• Unit blocked (UNIT BLOCK ON/OFF)
• Timing Blocked (TIMING BLOCK ON/OFF)
• Tripping Blocked (TRIPPING BLOCK ON/OFF)
• Trip (TRIP ON)
• No trip by counter direction (NO TRIP DIR ON)
• No trip by blocked unit (NO TRIP BLOCK ON)
Timed overvoltage unit
(UNIT 59-T)
Phase_1,2,3,N and NS
(P1)
(P2)
(P3)
(N)
(NS)
• Curve started up (PICK UP ON/OFF)
• Curve met (TEMPORIZED ON/OFF)
• Unit blocked (UNIT BLOCK ON/OFF)
• Timing Blocked (TIMING BLOCK ON/OFF)
• Tripping Blocked (TRIPPING BLOCK ON/OFF)
• Trip (TRIP ON)
• No trip by blocked unit (NO TRIP BLOCK ON)
Instantaneous overvoltage
unit
(UNIT 59-I)
Phase_1,2,3,N and NS
(P1)
(P2)
(P3)
(N)
(NS)
• Curve started up (PICK UP ON/OFF)
• Curve met (TEMPORIZED ON/OFF)
• Unit blocked (UNIT BLOCK ON/OFF)
• Timing Blocked (TIMING BLOCK ON/OFF)
• Tripping Blocked (TRIPPING BLOCK ON/OFF)
• Trip (TRIP ON)
• No trip by blocked unit (NO TRIP BLOCK ON)
Timed undervoltage unit
(UNIT 27-T)
Phase_1,2,3,N and NS
(P1)
(P2)
(P3)
(N)
(NS)
• Curve started up (PICK UP ON/OFF)
• Curve met (TEMPORIZED ON/OFF)
• Unit blocked (UNIT BLOCK ON/OFF)
• Timing Blocked (TIMING BLOCK ON/OFF)
• Tripping Blocked (TRIPPING BLOCK ON/OFF)
• Trip (TRIP ON)
• No trip by blocked unit (NO TRIP BLOCK ON)
Instantaneous
undervoltage unit
(UNIT 27-I)
Phase_1,2,3,N and NS
(P1)
(P2)
(P3)
(N)
(NS)
• Curve started up (PICK UP ON/OFF)
• Curve met (TEMPORIZED ON/OFF)
• Unit blocked (UNIT BLOCK ON/OFF)
• Timing Blocked (TIMING BLOCK ON/OFF)
• Tripping Blocked (TRIPPING BLOCK ON/OFF)
• Trip (TRIP ON)
• No trip by blocked unit (NO TRIP BLOCK ON)
