Ormazabal ekor.rpa Series User Manual

IG-267-EN versión 01; 07/04/2017
79
General Instructions
ekor.rpa
User configuration settings
Communication settings (COMMUNICATION)
Node
Settings
Type Designation
Range
Min. Max. Step (unit)
COM_485
Peripheral number Perif_Num 1 99 1
Speed Baud rate 1200/2400/4800/9600/19200/38400 baud
Parity Parity No/Odd/Even
Length Length 7 8 1
Stop bits Stopbits 1 2 1
Protocol Protocol CIRBUS/MODBUS/PROCOME
COM_
VIRTUAL
Peripheral number Perif_Num 1 99 1
Protocol Protocol CIRBUS/MODBUS/PROCOME
Table 9.5. Communication
9.2. Date and time settings
Settings (LOCAL_TIME_CLOCK)
Node
Settings
Type Designation
Range
Min. Max. Step (unit)
Date
(DATE)
Day Day 1 31 1 (day)
Month Month 1 12 1 (month)
Year Year 1970 9999 1 (year)
Time
(TIME)
Time Time 0 23 1 (hour)
Minute Min 0 59 1 (minute)
Second Sec 0 59 1 (second)
Table 9.6. Date and time setting
9.3. Remote communication settings
IP addresses
Node
Settings
Type Designation Format
IP_Local
Local IP address IP_LOCAL 20 char (IP pattern)
Local IP mask MASK_LOCAL 20 char (IP pattern)
IP_RTU1
Dynamic IP IP_DYNAMIC 20 char (IP pattern)
Remote IP address IP_RTU1 20 char (IP pattern)
Remote IP mask MASK_RTU1 20 char (IP pattern)
Gateway GTW_RTU1 20 char (IP pattern)
IP_RTU2
Remote IP address IP_RTU2 20 char (IP pattern)
Remote IP mask MASK_RTU2 20 char (IP pattern)
Gateway GTW_RTU2 20 char (IP pattern)
Table 9.7. IP setting
