Ormazabal ekor.rpa Series User Manual

IG-267-EN versión 01; 07/04/2017
78
User configuration settings General Instructions
ekor.rpa
Automation settings (AUTOMATISM)
Node
Settings
Type Designation
Range
Min. Max. Step (unit)
Recloser automation
(RECLOSER)
Enabling the unit Enable ON/OFF
Number of reclosings Reclose_Number 0 4 1
First recl. time for phases Phase_Reclosing_Time_1 0.05 600.00 0.01 (s)
First recl. time for neutral
Neutral_Reclosing_
Time_1
0.05 600.00 0.01 (s)
Second recl. time for phases Phase_Reclosing_Time_2 1.00 600.00 0.01 (s)
Second recl. time for neutral
Neutral_Reclosing_
Time_2
1.00 600.00 0.01 (s)
Third recl. time for phases Phase_Reclosing_Time_3 1.00 600.00 0.01 (s)
Third recl. time for neutral
Neutral_Reclosing_
Time_3
1.00 600.00 0.01 (s)
Fourth recl. time for phases Phase_Reclosing_Time_4 1.00 600.00 0.01 (s)
Fourth recl. time for neutral
Neutral_Reclosing_
Time_4
1.00 600.00 0.01 (s)
Reclosing Permission for unit 50 Mask 50 ON/OFF
Reclosing Permission for unit 51 (1) Mask 51 ON/OFF
Reclosing Permission for unit 51 (2) Mask 51_2 ON/OFF
Reclosing Permission for unit 50N Mask 50N ON/OFF
Reclosing Permission for unit 51N (1) Mask 51N ON/OFF
Reclosing Permission for unit 51N (2) Mask 51N_2 ON/OFF
Reclosing Permission for unit 50NS Mask 50NS ON/OFF
Reclosing Permission for unit 51NS (1) Mask 51NS ON/OFF
Reclosing Permission for unit 51NS (2) Mask 51NS_2 ON/OFF
Reference voltage standby time Vref_Time 1.00 600.00 0.01 (s)
Safety time following phase fault
reclosing
Phase_Blocking_Time 1.00 600.00 0.01 (s)
Safety time following neutral fault
reclosing
Neutral_Blocking_Time 1.00 600.00 0.01 (s)
Safety time after external or manual
close
Manual_Blocking_Time 1.00 600.00 0.01 (s)
Switch error automation
(UNIT_50BF)
State method
(STATUS_METHOD)
Switch opening failure time Opening_Error_time 0.10 600.00 0.01 (s)
Switch closing failure time Closing_Error_Time 0.10 600.00 0.01 (s)
Voltage presence/
absence automation
(VOLTAGE PRESENCE_
ABSENCE)
Enabling the unit Enable ON/OFF
Line voltage Grid_Voltage 0.5 72.0 0.1 (kV)
Presence of voltage level Presence_Voltage 10.0 120.0 1.0 (%)
Absence of voltage level Absence_Voltage 10.0 120.0 1.0 (%)
Voltage presence/absence hysteresis Hysteresis_Voltage 0.0 100.0 0.1 (%)
Presence of voltage time Presence_Time 0.05 200.00 0.01 (s)
Absence of voltage time Absence_Time 0.05 200.00 0.01 (s)
Table 9.4. Automation
