Ormazabal ekor.rpa Series User Manual

IG-267-EN versión 01; 07/04/2017
81
General Instructions
ekor.rpa
Log record
10.1.2. Structure of the report
The fault report can be divided into five functional parts:
1. Information on the system the report belongs to.
2. Fault summary or report.
3. Status of system protection units at the moment of
the fault.
4. Current open by the switch.
5. Record of events generated during the time window of
the fault. This collects the instantaneous values of the
meterings (module, argument) along with each event.
Fault report
1
System (DEVICE): ekor.rpa -XXX-v/p
Serial number (S.N.): Aaabbccddd (family/year/week/unit)
… …
2
Start
(Fault Start)
Tripping order
(TRIP Command)
End of Fault
(Fault end)
dd-mm-yy_hh-mm-ss-ms dd-mm-yy_hh-mm-ss-ms dd-mm-yy_hh-mm-ss-ms
Fault type
(Trip type)
Tripping time
(Trip time)
Length of fault
(Fault Duration)
Unit_Type-Group-Subgroup xxx.xxx.xxx (ms) xxx.xxx.xxx (ms)
3
Available units
(Available units)
Enabled
(Enable)
Started-up
(Picked up)
Curve met
(Temporized)
Tripped
(Tripped)
Unit_Node-Phase-Temp. No (Empty)/Yes (X) No (Empty)/Yes (X) No (Empty)/Yes (X) No (Empty)/Yes (X)
... … … … …
4
Switch opening current
(TRIPPED Current):
Phase 1: Module (A) Argument (º)
Phase 2: Module (A) Argument (º)
Phase 3: Module (A) Argument (º)
Neutral (N.C.): Module (A) Argument (º)
N. Sensitive (N.S.): Module (A) Argument (º)
5
Event record (Event Record) Date/Time Phasor currents and voltages
Pre-fault event
Date: dd-mm-yy
Time: hh-mm-ss-ms
Phase 1: Module (A/kV))/Argument (°)
Phase 2: Module (A/kV))/Argument (°)
Phase 3: Module (A/kV))/Argument (°)
Phase N: Module (A/kV))/Argument (°)
Phase N.s: Module (A/kV))/Argument (°)
Unit_Type-Group-Subgroup_Signal-ON/OFF
Date: dd-mm-yy
Time: hh-mm-ss-ms
Phase 1: Module (A/kV))/Argument (°)
Phase 2: Module (A/kV))/Argument (°)
Phase 3: Module (A/kV))/Argument (°)
Phase N: Module (A/kV))/Argument (°)
Phase N.s: Module (A/kV))/Argument (°)
... … …
Close Fault Report_Reason for close
Date: dd-mm-yy
Time: hh-mm-ss-ms
Empty
Table 10.1. Fault report (FAULT REPORT)
