Ormazabal ekor.rpa Series User Manual

IG-267-EN versión 01; 07/04/2017
74
User configuration settings General Instructions
ekor.rpa
Protection settings (PROTECTION)
Type Class Node
Settings
Type Designation
Range
Min. Max. Step (unit)
Current protection
(CURRENT_PROTECTION)
Overcurrent protection
(OVERCURRENT)
Phase timed
unit (1)
(UNIT_51)
Enabling the unit Enable ON/OFF
Starting up the unit Pick_up*
5.0
15.0
37.5
6000.0
20 000.0
50 000.0
0.1 (A)
0.1 (A)
0.1 (A)
Time curve Curve
IEC: DT, NI, VI, EI, STI and LTI
ANSI: NI, VI, EI and LI
Inverse curve time index Index 0.05 1.60 0.01
Fixed time Time 0.00 100.00 0.01 (s)
Torque control Direction OFF/FORWARD/REVERSE
Phase timed
unit (2)
(UNIT_51_2)
Enabling the unit Enable ON/OFF
Starting up the unit Pick_up*
5.0
15.0
37.5
6000.0
20,000.0
50,000.0
0.1 (A)
0.1 (A)
0.1 (A)
Time curve Curve
IEC: DT, NI, VI, EI, STI and LTI
ANSI: NI, VI, EI and LI
Inverse curve time index Index 0.05 1.60 0.01
Fixed time Time 0.00 100.00 0.01 (s)
Torque control Direction OFF/FORWARD/REVERSE
Phase
instantaneous
unit (1)
(UNIT_50)
Enabling the unit Enable ON/OFF
Starting up the unit Pick_up*
5.0
15.0
37.5
6000.0
20,000.0
50,000.0
0.1 (A)
0.1 (A)
0.1 (A)
Unit timing Time 0.00 100.00 0.01 (s)
Torque control Direction OFF/FORWARD/REVERSE
Neutral timed
unit (1)
(UNIT_51N)
Enabling the unit Enable ON/OFF
Starting up the unit Pick_up*
5.0
15.0
37.5
6000.0
20,000.0
50,000.0
0.1 (A)
0.1 (A)
0.1 (A)
Time curve Curve
IEC: DT, NI, VI, EI, STI and LTI
ANSI: NI, VI, EI and LI
Inverse curve time index Index 0.05 1.60 0.01
Fixed time Time 0.00 100.00 0.01 (s)
Torque control Direction OFF/FORWARD/REVERSE
Neutral timed
unit (2)
(UNIT_51_2_N)
Enabling the unit Enable ON/OFF
Starting up the unit Pick_up*
5.0
15.0
37.5
6000.0
20,000.0
50,000.0
0.1 (A)
0.1 (A)
0.1 (A)
Time curve Curve
IEC: DT, NI, VI, EI, STI and LTI
ANSI: NI, VI, EI and LI
Inverse curve time index Index 0.05 1.60 0.01
Fixed time Time 0.00 100.00 0.01 (s)
Torque control Direction OFF/FORWARD/REVERSE
Neutral
instantaneous
unit
(UNIT_50N)
Enabling the unit Enable ON/OFF
Starting up the unit Pick_up*
5.0
15.0
37.5
6000.0
20,000.0
50,000.0
0.1 (A)
0.1 (A)
0.1 (A)
Unit timing Time 0.00 100.00 0.01 (s)
Torque control Direction OFF/FORWARD/REVERSE
Continued on next page
