932502G / 0618 7. FIRMWARE COMMANDS AND RESPONSES
SHOW_RENH
Reports if Resolution Enhancer mode is enabled.
Responses:
$IF Resolution Enhancer mode disabled.
$IT Resolution Enhancer mode enabled.
SHOW_ROI
Used in conjunction with the SHOW_NEXT command, SHOW_ROI reports the first
continuous group of channels that have the ROI flag set. The response is of the form:
$Dsssssnnnnnccc<CR>
where sssss represents an integer number that is the number of the first channel of the “first”
group of channels that all have their ROI bit set, and nnnnn represents an integer number
that is the number of channels in the group. The SHOW_NEXT command is used to report
the “next” group of channels that all have their ROI bit set.
Responses:
$D0100000050078<CR> First ROI starts at channel 1000 and is 50 channels long.
$D0215000150086<CR> First ROI starts at channel 2150 and is 150 channels long.
$D0000000000072<CR> No ROI groups to report.
SHOW_ROI_MDA
Reports the start channel and number of channels used in the MDA preset calculation.
Example Response:
$D0700000050ccc Calculation is performed on channels 7000–7049.
SHOW_ROI_SAMPLE
Displays the ROI Sample setting. See also SET_ROI_SAMPLE.
Responses:
$C00001088
SHOW_ROI_UNCERTAINTY
Reports the start channel and number of channels used in the uncertainty preset calculation.
See also SET_ROI_UNCERTAINTY.
Response:
$D0700000050ccc Calculation is performed on channels 7000–7049.
SHOW_SCA
Returns the SCA settings. See also SET_SCA.
Responses:
$D1000012000076 SCA lower channel is 10000 and upper channel is 12000.
SHOW_SCA_OUTPUT
113
