OSOYOO V2.1 - Lesson 8 Hardware Installation

82
2
Buzzer Sensor
Module
1
click here
Click here to
buy
3
IR transmitter
1
Click here to
buy
4
20Pin jumper wire
Male to female
20cm
some
5
M3 plastic screw
5
6
M3 plastic pillar
5
7
M3 plastic nut
5
Hardware Installation
Step 1:This project needs at least two Osoyoo V2 Arduino Robots. In each
robot, Lesson 7 hardware installation must have been completed.
Step 2: Install IR receiver (Lesson 2) and buzzer module (lesson 5) and add
IR transmitter with 2pcs M3 plastic screws, pillars and nuts as following:
