Setup Manual - Butler XT2
Network parameters
Device Basics
Device Name The device will be displayed with this name in the e:cue
programmer.
IP address The IP address of the device (default: 192.168.123.1)
Subnet Mask The netmask of the device (Default: 255.255.255.0)
Gateway address The default gateway of the device (Default: no gateway)
MAC address The physical address of the device (read only)
Base Time - Date The base time/date of the device. This is the time to
which the Daylight Saving Time offset is added.
DST Time - Date The current real time and date with DST shift.
DST Info Information about the DST settings, shift and date
range
Group ID Group ID for the cluster configuration.
Password Apply a password to protect the configuration. Default
is “ecue”.
UPNP enable Enable Universal Plug and Play for the IP network.
Versions
Hardware Build Version The hardware version (read only).
Software Build Version The software version (read only).
Cluster Mode
Cluster ID Generated ID of the cluster
Cluster Size Number of engines in this cluster
Device Mode Master or Slave n/m (n of m)
Advanced Setup
Lock Settings Checkmark, set by default, avoids changes for DMX
and RDM by chance.
BRK Length Break signal length in µs for the DMX protocol.
MAB Length Mark after break length in µs for the DMX protocol.
BRK Length RDM Break length in µs for the RDM protocol.
MAB Length RDM Mark after break length in µs for the RDM protocol.
RDM Switch Time The RDM Tx to Rx length in in µs.
BRK Length Break length for e:pix protocol (not used).
MAB Length Mark after break length for e:pix protocol (not used).
RTC Trim Adjust the internal real time clock (RTC), value is sec-
onds per 28 days.
RTC Trim Fine Additional fine adjustment for the RTC.
