47
Adjust the desired depth of the hip support retainers and fix each with the two adjustment screws
(Fig. 8).
Slide the hip supports over the retainers and attach with hook & loop straps. Put the lateral sup-
port pads (Fig. 9) onto the plastic retainers with the padding side towards the inside and secure
them with the hook & look closures.
8 9
Information!
The storage bag is attached to the frame with straps and snap fasteners. To do this,
please thread the corresponding straps through the eyelets on the right and left of
the rear frame (Fig. 10, item A) and around the frame tube of the central frame (Fig.
10, item B). Use the snap fasteners to attach the straps.
10
B
A
