Note: Cable pinout for Type 3 cables are the same for both Zinc and Stainless Steel connectors.
Type1andType2 cablespecificationsareforreferenceonlyareNO longer available forpurchase.
CablePinoutDiagramforType4(1000BASE-T1)
Table4.3: Type4(1000BASE-T1)
Fig.4.3: Type4(1000BASE-T1)
Fig.4.4: Type4(1000BASE-T1)CADDrawing
Table4.4: PinoutandwiregaugesforType4(1000BASE-T1)cables
NetName Pin
No.
Wire
Color
Type-4,
Base1000T1
Twisted
with
Color
(Display)
VCC 1 Red 18AWG NA
GROUND 7 Black 18AWG NA
MULTIPURPOSE_IO 3 Purple 28AWG NA
SYNC_PULSE_IN 2 Yellow 28AWG NA
EthernetBI_DA+ 12 Blue 26AWG White
EthernetBI_DA- 11 White 26AWG Blue
Warning: Ousterisnotresponsibleforanyerrorsinwiringasaresultof bypassingtheInterface
Boxandthisactivitymayresultinvoidingofyourwarrantyifitresultsindamagetothesensor.
Thefollowingguidelinesfordirect cable connection assume use of the Ouster-provided24V1.5A
powersupply. Oustercannotbeheldresponsiblefordamagetothedeviceifanalternateisused.
