5.Advanced User Guidebook
The description of the Channel Menu is shown as the following list:
Function
Menu
Setting Description
Coupling
DC
AC
GROUND
Pass both AC and DC components of the input signal.
Block the DC component of the input signal.
Disconnect the input signal.
Inverted
ON
OFF
Display inverted waveform.
Display original waveform.
Attenu
X1
X10
X100
X1000
Match this to the probe attenuation factor to have an
accurate reading of vertical scale.
MeasCurr
YES
NO
If you are measuring current by probing the voltage
drop across a resistor, choose YES.
Probe
A/V (mA/V)
V/A (mV/A)
Turn the M knob to set the Amps/Volts ratio.
Amps/Volts ratio
= 1/Resistor value
Volts/Amp ratio is automatically calculated.
Limit
(SDS6062(V)
does not have
this function)
full band
20M
Get full bandwidth.
Limit the channel bandwidth to 20MHz to reduce
display noise.
1. To set channel coupling
Taking the Channel 1 for example, the measured signal is a square wave signal
containing the direct current bias. The operation steps are shown as below:
(1) Press the CH1 MENU button to show CH1 SETUP menu.
(2) Press the H1 button, the Coupling menu will display at the screen.
(3) Press the F1 button to select the Coupling item as "DC". Both DC and AC
components of the signal are passed. The waveforms are shown as Figure
5-2.
(4) Then, press F2 button to select the Coupling item as "AC". The direct current
component of the signal is blocked. The waveforms are shown as Figure 5-3.
