8.Technical Specifications
8. Technical Specifications
Unless otherwise specified, the technical specifications applied are for SDS series
only, and Probes attenuation set as 10X. Only if the oscilloscope fulfills the following
two conditions at first, these specification standards can be reached.
 This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
 If change of the operating temperature is up to or exceeds 5 , ℃ do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on P15).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Performance Characteristics Instruction
SDS6062(V) 60MHz
SDS7102(V) 100MHz
SDS8102(V) 100MHz
SDS8202(V) 200MHz
SDS8302 300MHz
Bandwidth
SDS9302 300MHz
Channel
2 + 1 (External)
Mode Normal, Peak detect, Averaging
Dual CH 250MS/s
SDS6062(V)
Single CH 500MS/s
Dual CH 500MS/s
SDS7102(V)
Single CH 1GS/s
Dual CH 1GS/s
SDS8102(V)
Single CH 2GS/s
Dual CH 1GS/s
SDS8202(V)
Single CH 2GS/s
Dual CH 1.25GS/s
SDS8302
Single CH 2.5GS/s
Dual CH 1.6GS/s
Acquisition
Sample rate
(real time)
SDS9302
Single CH 3.2GS/s
Input coupling DC, AC , Ground
Input impedance 1MΩ±2%, in parallel with 10pF±5pF
Probe attenuation
factor
1X, 10X, 100X, 1000X
Max. input voltage 400V (PK-PK) (DC + AC PK-PK)
Input
Bandwidth limit
20MHz, full bandwidth
(not including SDS6062(V) )
86
