Owon SDS series User Manual

8.Technical Specifications
Performance Characteristics Instruction
Channel –channel
isolation
50Hz: 100 : 1
10MHz: 40 : 1
Time delay between
channel(typical)
150ps
Dual CH 0.5S/s~250MS/s
SDS6062(V)
Single CH 0.5S/s~500MS/s
Dual CH 0.5S/s~500MS/s
SDS7102(V)
Single CH 0.5S/s~1GS/s
Dual CH 0.5S/s~1GS/s
SDS8102(V)
Single CH 0.5S/s~2GS/s
Dual CH 0.5S/s~1GS/s
SDS8202(V)
Single CH 0.5S/s~2GS/s
Dual CH 0.5S/s~1.25GS/s
SDS8302
Single CH 0.5S/s~2.5GS/s
Dual CH 0.5S/s~1.6GS/s
Sampling rate range
SDS9302
Single CH 0.5S/s~3.2GS/s
Interpolation (sin x)/x
Dual CH
SDS6062(V)
Single CH
≤Max
sampling rate
10M
Dual CH
SDS7102(V)
Single CH
≤Max
sampling rate
10M
≤500MS/s
10M
Dual CH
1GS/s 10K
≤1GS/s
10M
SDS8102(V)
Single CH
2GS/s 10K
≤500MS/s
10M
Dual CH
1GS/s 10K
≤1GS/s
10M
SDS8202(V)
Single CH
2GS/s 10K
≤500MS/s
10M
Dual CH
1GS/s
1.25GS/s
10K
≤1GS/s
10M
Horizontal
System
Max Record length
SDS8302
Single CH
2GS/s
2.5GS/s
10K
87
