Owon SDS series User Manual

5.Advanced User Guidebook
Setting
Setting1
…..
Setting8
The setting address
Save
Save the current oscilloscope setting to the
internal storage
Load Recall the setting from the selected address
When the type is Image, the menu shows as following:
Save
Save the current display screen. The file
can be only stored in a USB storage, so a
USB storage must be connected first. The
file name is editable. The file is stored in
BMP format.
Save and Recall the Waveform
The SDS series oscilloscope can store 15 waveforms, which can be displayed with the
current waveform at the same time. The stored waveform called out can not be
adjusted.
In order to save the waveform of the CH1 into the address 1, the operation steps
should be followed:
1. Saving: Press the H1 button, the Type menu will display at the left of screen,
turn the M knob to choose Wave for Type.
2. Press the H2 button and press F1 button to select CH1 for Source.
3. Press the H3 button and press the F1, turn the M knob to select 1 as object
address.
4. Press the H5 button and press F1 button to select Internal.
5. Press the H4 button to save the waveform.
6. Recalling: Press the H3 button, and press the F1, turn the M knob to select 1 as
object address. Press F2 button to set Show as ON. The waveform stored in the
address will be shown, the address number and relevant information will be
displayed at the top left of the screen.
50
