OVERVIEW
CONTROL HEAD
The control head engages both gear
shiing and acceleration. Depending
on single installation or multi
installation of outboards, the boat
is equipped with a single or twin
shi control head. This description
comprises a single shi control head
only. Also refer to Single Control
Head Manual or Twin Control
Head Manual.
1. Engine trim control
2. Control lever
3. Lever position indicator
4. Control lamp
5. Neutral button
6. SEL button
7. Indicator lamp
INSTRUMENTATION
For instruments and gauges, refer
to corresponding Display manual.
1
3
6
7
4
2
5
