11
Low Speed Control
Normal propeller
rpm range:
idle to max rpm
LSC propeller rpm range:
0 to idle rpm
Low Speed Control (LSC)
enables unprecedented control
while mooring and low speed
maneuvering. LSC incorporates
an electro-hydraulically operated
clutch that ensures smooth shiing
between neutral, forward and
reverse.
The sensor controlled propeller
speed allows for seamless control
from zero to maximum rpm. The
boat is fully operable even below
3-4 knots.
Trolling Mode
When engaging Trolling Mode (TM)
the full throttle range represents
20% of normal throttle range. This
enables a higher resolution of the
throttle maneuvering thus giving the
operator a more precise control in
demanding situations.
Trolling propeller rpm range:
Zero to idle rpm
Full engagement
propeller rpm range
idle to 20% of max rpm
A very slow flashing (one second
on, one second off) neutral indicator
lamp (7) indicates that TM is
engaged.
Engaging Trolling Mode
Move the control lever (2) to
forward idle or reverse idle
positions.
Press the N button (5). The lamp (7)
will flash slowly to indicate that TM
is engaged.
Disengaging Trolling Mode
Move the control lever (2) to
forward idle or reverse idle position.
Press the N button (5). The flashing
lamp (7) will go out to indicate that
TM is disengaged.
