21
Check fluid level in power trim and tilt unit
2. Remove the filling plug (3) and
seal (4). Check the fluid level in
the reservoir.
NOTE! If the fluid is correctly
levelled, only a small amount of fluid
should come out of the filling hole
when the plug is removed.
3. If necessary, fill up with fluid
of recommended type until it
comes out of the filling hole.
1. Tilt up the outboard completely
and support the tilt cylinder
with a transom saver (1).
!
WARNING
Make sure to support the
outboard with the transom tilt
saver. Otherwise the outboard
can fall down accidentally if the
power tilt and trim unit looses
pressure.
!
WARNING
Ensure that the trim and tilt rods (2)
are fully extended when the plug
is removed. Otherwise the fluid
can spray from the reservoir due
to internal pressure.
