90°
90°
Flat Surface
Install main shaft with frame assembly
on a flat surface, push down on both frames
together and then fully tighten all M2x5 hex cap
screws (x12) holding the bearing blocks.
Page 13
Step 05
Main Frame Assembly.
(CNC components)
Chapter 8, Align and Lock Frame Panels
To Next Page
