Paccar MX-13 Programming Guide

PEC017
5/3/2018 Page 70 of 105
PS27
Page 68
Min
Default
Max
Units
PGS First Engine Speed Limit
1400
N/A
PS29
RPM
*Minimum engine speed limit is 1400 RPM to ensure proper control system stability
when PGS is active
*Maximum engine speed limit is 1650 RPM to ensure the proper balance between
fuel economy shifting and providing power while accelerating
PS28
Page 67
Min
Default
Max
Units
PGS First Limit Gear Max
>PS26
N/A
<PS30
GEAR #
*Never program PGS to be active in top gear
PS29
Page 67
Min
Default
Max
Units
PGS Second Engine Speed Limit
PS27
N/A
1800
RPM
*The minimum RPM after a shift in any gear should not fall below 1100 RPM
PS30
Page 67
Min
Default
Max
Units
PGS Highest Gear
>PS30
N/A
*
GEAR #
*Never program PGS to be active in top gear
ON/OFF Requirements
Progressive Shift
ON
OFF
ENTER SALES CODE
(Progressive Shift ON)
No Sales Code
(Progressive Shift OFF)
GDP
ON
OFF
ENTER SALES CODE
(Gear Down Protection ON)
No Sales Code
(Gear Down Protection OFF)

Paccar MX-13 Specifications

General

Engine Type	Diesel
Displacement	12.9 liters
Configuration	Inline 6-cylinder
Horsepower Range	405-510 hp
Torque Range	1450-1850 lb-ft
Bore	5.12 inches
Fuel System	Common Rail
Emissions	GHG17 compliant
Oil Capacity	42 quarts
Coolant Capacity	56 liters
Aftertreatment	Diesel Particulate Filter (DPF), Selective Catalytic Reduction (SCR)
Stroke	6.42 inches (163 mm)
