ENGINEIDENTIFICATION
1.Dataplate
2.ESN
Iftheenginedataplate(1)isnot
readable,theESN(2)canbe
foundontheengineblockontop
ofthelubricatingoilcoolerhousing.
Additionalengineinformationison
theelectroniccontrolmodule(ECM)
dataplate.
FuelInjectionPump
Dataplate
Thefuelinjectionpumpdataplateis
locatedonthefuelpump.
Thedataplatecontainsthefollowing
informationtoassistinservicingor
replacement:
1.Partnumber
2.Pumpserialnumber
3.Factorycode
EngineControlModule
Dataplate
NOTE
NotallengineshaveECMdata-
plates.
Enginescoveredbythismanual
areequippedwithaCM2350ECM.
ACM2350ECMhastwo96-pin
connectors.Oneofthe96-pin
connectorsisforengineinputsand
outputsonly.Thesecond96-pin
connectorand14-pinconnectorarefor
6-
4Y53-1185-1B1(12/2014)
