QUICK CONTROLLER OVERVIEW
The front panel of the C36 has a pair of blue LEDs. See the below table for more information.
When lit, the hard drive is in use
When lit, indicates that unit has power
The rear panel is where the physical cabling (power, ethernet, console) is located. The table below
describes each port and its function.
Switch to power on or off the C36
MDI/MDIX RJ45 Interface for connection to the LAN
HDMI Display out for Maintenance
Local management, Speed 115200bps, RJ45 interface
