1.6 The main dimensions and models of the machine
Item
Powered by tractor
TR /operated
by electricity
Powered by
combustion engine
Output
- 7.5 kW
13 hp
Fuse size
- 16 A
-
Weight
660 kg
720 kg
710 kg
Height/width/length
2400 mm x 2,830mm x 1,450mm
Crosscut deck
Length 950 mm, with extension table
1,950 mm
Height of crosscut deck
800 mm
Diameter of blade/hole
700/ 35 mm
Max. rotation speed of blade
2000 r.p.m.
Max. diameter of the log
25cm
Max. length of tree, splitting
600 mm
1.7 Safety instructions
General regulations and restrictions
The maximum length of the log to be cut is 4 metres. Danger of turning over!
The machine is exclusively intended for the production of firewood.
The machine may only be operated by one person.
The machine must be equipped with appropriate lights and reflectors for
transportation on public roads.
The danger zone around the conveyor is 5 metres to the sides and to the rear
Always lock the crosscut deck in the rear position for transportation.
Always shift and lock the table extension into its rear position for transportation.
The three-point linkage of the tractor is of size-category two. If using a tractor larger
in size, check that there is sufficiently space for the PTO-shaft and its protective
guard.
Never use the machine indoors – risk of dust generation. The use of a machine
powered by combustion engine involves danger of exhaust gases.
Never remove any safety-related devices from the machine.
The width of the machine equipped with the 4,3-m conveyor is about 2.83 m. This
means that, depending on the size of the tractor, the transport width of the
conveyor may extend outside the rear wheel on the right-hand side.
The operator
Every person operating the machine, must thoroughly study the entire user
manual.
Always use eye guards and hearing protectors.
Always wear protective shoes.
Always wear work gloves.
Do not wear loosely-fitting clothing.
Before use
Make sure that all other people stay outside the operating range.
Always hitch the tractor-driven machine to the three-point linkage. Also ensure that
sufficient space is provided for the PTO-shaft and its guard.
