cod. 00 477 1480 - 12/2012 - Palazzetti - PN - Italy 47/164
ENGLISH
INSTALLATION
6.1.1 Installation without base frame
It is possible to install the built-in with front
Procedure:
1) Slide the stove off the base(Fig. 6.1.7);
2) Use plugs to position and fasten the base to
3) Re-install the telescopic guides and re-insert
the stove in the base (Fig. 6.1.9);
4) Arrange the pellet chute according to needs
using commercially available materials to be
be carved in order to allow the circulation of fresh
air to avoid overheating of the appliance.
Fig. 6.1.7
Fig. 6.1.8
Fig. 6.1.9
