ILF 33/44/55 Installation Manual
Rev 1.1 14
6 Chassis and Body Preparation
Installation Dimensions 6.1
IMPORTANT:
Always use the smallest F-dim possible for best ground clearance
(Don‟t exceed max. ground clearance)
Minimum bed height is when truck/trailer is loaded to MAX GVW
"K"
Mount Clearance
(Reference)
"F" Dim.
Bed Height
Max. 62"
Min. 46"
"G"
Ground
Clearance
Sill
ILF 33 Mounting Dimension Table
Bed Height
(Loaded)
F
Dim.
G
Dim.
K
Dim.
(Ref.)
62“
33“
20“
29“
58“
32“
19“
30“
56“
31“
18“
31“
54“
30“
17“
31.5“
52“
29“
16“
32.5“
50“
28“
15“
33“
48“
27“
14“
34“
46“
26“
13“
35“
