ILF 33/44/55 Installation Manual
Rev 1.1 52
12 Decal Placement and Inspection
For operator safety, all decals appearing in “Decal Kit” must be in a conspicuous place on control side of
liftgate. This is typically a combination of decals on the liftgate and truck or trailer body. Please make sure to
place the maximum capacity decal (C) on driver and curb side.
Important: Never remove or paint over any decal. If any decals below require replacement contact
Palfinger Liftgates.
Urgent Warning: Elevating gate instructions
Circuit Breaker Reset (must be placed where the circuit
breaker was installed)
Capacity (please check the serial number plate to find out your
specific capacity)
Circuit Breaker Protection
Warning: liftgate can crush
Caution: Always stand clear of platform area
Liftgate Shut-Off (Place Decal next to the On-Off Switch in the
Cab)
Warning: Use handle to open (Must be located underneath
handle (main section)
Conspicuity Tape (Place tape along bumper)
Operating Instructions (Place in control box)
Operating Instructions (Place on the curb side of vehicle body
above control box)
*Stake and Flatbed Vehicles: It is recommended to install a plate on the stakes of the vehicle to serve as a
surface to install Decal L. Part number 60-0115-200 maybe used for flatbed vehicles with no stakes. Fig. 27.
It is the installer„s responsibility to determine the proper application of the Conspicuity tape (J), and to
ensure that the vehicle meets DOT and federal lighting regulations. Keep in mind that there are
different requirements depending on the classification of the vehicle. This document is not intended to
replace published agency regulations, and it is strongly recommended that the installer references the
Code of Federal Regulations (CFR) which can be viewed at http://www.ecfr.gov.
