Palfinger ILF 33 - Important Dimensions; Recommended Tools

ILF 33/44/55 Installation Manual
Rev 1.1 9
Important Dimensions 3.1
Minimum Bed Height dimensions are ALWAYS MAXIMUM LOADED TRUCK.
Maximum Bed Height dimensions are ALWAYS DRY UNLOADED TRUCK.
 Installing a gate at or close to minimum bed height normally results in a gate that will NOT open
and close from stored position if the minimum floor height is exceeded when truck is loaded.
 Ensure trailer body does not interfere with installation or operation of the ILF liftgate series.
 It is not recommended to cut, torch, or remove support materials from trailer. Removing gussets,
stiffeners, light rings, or other such support structures may VOID your trailer warranty.
 Call technical support before starting the installation if any questions or concerns arise on
mounting dimensions or procedures.
Mounting Notes:
Read and clearly understand manual BEFORE beginning ANY work.
The basic rule of PALFINGER Liftgates‟s ILF installation is to lift mount frame
to achieve MAXIMUM ground clearance WITHOUT exceeding Min “F” dimension.
Recommended Tools 3.2
Metric Wrench Set
Basic Screwdrivers
Pliers
Wire Crimp Pliers
Digital Multimeter
Snap Ring Pliers
Hammer
Metric Allen Set 1.5mm-10mm
½” Impact & Sockets
Sm. Metric Socket Set
Assorted Drill Bits
Floor Jack or Equiv.
Sm. To Med. Bottle Jack
Forklift or O/H Crane
Hand Held Grinder
Paint Gun
Cutting Torch or Equiv.
3/8 Drill Motor
Pry Bar
Heat Gun or Equiv.
Min. 250 Amp Welder
