Palfinger ILP - 4.4 Bed Height Ranges: Unloaded Truck 800 mm Arm

Installation Dimensions
Revision 1.3 - 12 -
4.4 Bed Height Ranges: Unloaded Truck 800mm Arm
2"x3"x3/16" Angle
1/4"x3" HR Flat
Frame Cap
Not Supplied
Not Supplied
38"
12"
17-1/2"
12"
12"
16-1/2"
13-1/2"
800 mm
15"
12"
15-1/2"
13"
12"
19-1/2"
Min laden
bed height
Max
bedheight
43-1/2"
53"
51"
47-1/2"
31-1/2"
Basic frame cut out and installation information ILP - ROUND TUBE
Bedheights covered: 38", 43", 47", 51" and 53"
Assuming 22" F-Dim
Assuming 23" F-Dim
Assuming 27" F-Dim
Assuming 25" F-Dim
Assuming 29" F-Dim
12"
14-1/2"
15-1/2"
Figure 7 Frame cap suggestions related to bed height
