Gate Overview and Components
Revision 1.3 - 5 -
Lift Cylinders
Roller
Hydraulic Power Unit
Bed Extension
Platform
Mount Plates
Parallel Arm
Lift Arm
Mount Frame
Center of Gravity
2 Gate Overview and Components
Figure 1 Liftgate overview with component description
A liftgate contains three (3) main objectives:
1) Foldable platform with shackles and coil springs
2) Lift arm assembly with parallel arms and lift cylinder
3) Main frame with roll over assembly and power pack enclosure
Rubber
Snubber
