Installation Dimensions
Revision 1.3 - 14 -
4.6 Bed Height Ranges: Unloaded Truck 900mm Arm
Assuming 26" F-Dim
Assuming 27" F-Dim
Assuming 29" F-Dim
Basic frame cut out and installation information
ILP 900 mm Arm (35") 54"Platform
Bed heights covered: 45", 47", 51" and 55"
Use the closest to your application
These dimensions are starting points. Your final dimensions may vary
depending on actual installation F-Dim
Refer to chapter 3 and 4
Assuming 28" F-Dim
12"
12"
12"
(900 mm)
35-1/2"
2"x3"x3/16" Angle
1/4"x3" HR Flat
Frame Cap
Not Supplied
Not Supplied
15-3/4"
22-1/4"
17"
21-1/2"
12"
18-1-4"
21"
19-1/2"
20-1/2"
Cut-out vertical
Cut-out horizontal
Figure 9 Frame Cap suggestions related to bed height 900mm
